Description:

• 98 gal./min. capacity
• 57 psi max.
• Cast iron volute and impeller

Specification:

• Engine Model: GX120
• Displacement: 118 cc
• Bore and Stroke: 2.4" x 1.7"
• Compression Ratio: 8.5:1
• Oil Alert: N/A

Pump Specifications:

• Pump Type: High Pressure, Centrifugal, Self-priming
• Volute: Rigid Mounted Cast Iron
• Impeller: Cast Iron
• Mechanical Seal (Pump case / impeller): Carbon/Ceramic
• Priming Time: 80 seconds at 16.4 ft.
• Drive System: Direct
• Discharge Capacity: 98 gallons per minute
• Suction Port Diameter: 1.5" NPT
• Discharge Port Diameter: 1.5" NPT
• Total Head Lift: 131 ft.
• Suction Head Lift: 26 ft.
• Maximum Pressure: 57 psi
• Solids Handling: N/A

Dimensions and Weight:

• Dimensions (LxWxH): 16.3" x 14.2" x 16.3"
• Dry Weight: 49 lbs.

Fuel and Operation:

• Fuel Capacity: 0.53 gallons
• Run Time at Max Discharge: 1.5 hours

Additional Information:

• Strainer Part #: 78325-YB7-020

Warranty:

• Residential Warranty: 24 months
• Commercial Warranty: 12 months
