Description:

• Commercial-grade 25.5 hp Kawasaki® FX801V (852cc) engine
• A fully fabricated 54-inch 10-gauge steel commercial deck shell with top bottom and side reinforcements plus standard 24" tires give you more ground clearance to easily hop on curbs.
• A large, fully adjustable suspension platform allows you to adjust tension and glide comfortably through tough terrains.
• High-performance commercial Hydro-Gear® PK 12cc pumps & Parker® TL 240cc wheel motors deliver quick response to the drive wheels and smooth control for cutting speeds up to 10 mph.
• 3-year limited commercial warranty (no hour limitations) and 5-year/1,750-hour limited deck assembly warranty.

Specifications:

Engine

• Brand: Kawasaki
• Model: FX Series
• Model Number: 801V
• Displacement: 852cc
• Output: 25.5HP
• Starter Type: Electronic
• Fuel Tank Capacity: 7.5 gal. US (28.4 L)

Transmission and Drive

• Transmission: 12cc Hydro-Gear pumps / 240cc Parker wheel motors
• Forward Speed: 10 mph / 16 km/h
• Reverse Speed: 5 mph / 8 km/h

Cutting Deck

• Deck Cutting Width: 54 in
• Deck Material: 10-gauge steel
• Deck Engagement (PTO): Electronic with quick reset
• Blade(s): Three 19" long high-lift Marbain blades, 1-1/2" of blade overlap

Chassis and Suspension

• Frame: 2" x 3" full-length tube frame
• Front Axle: 2" x 3" tube construction
• Front Caster Mount: 3/8" thick steel
• Suspension: Hand lever adjust, 3-position spring suspension foot platform

Controls and Brakes

• Cruise Control: NA
• Brakes: Hand lever control / external band
• Steering Control: Lap Bar Steering Wheel Control

Wheels and Tires

• Rear Tires: 24"x12"-12"
• Front Tires: 13x5-6" Reliance Run Flat Carlisle

Dimensions and Weight

• Length/Width/Height: 69" / 68" / 56"
• Weight (approx.): 1080 lbs

Additional Specifications

• Hour Meter: Yes
• Warranty:
• Residential Warranty: 3-year / no-hour-limit warranty
• Deck Shell Warranty: 5-year / 1,750 hour limited manufacturer’s warranty
